Dakota Lithium - 100W Flexible Solar Panel Kit - 12v100wsolarpanel

For limitless freedom, use the Dakota Lithium - 100W Flexible Solar Panel Kit - 12v100wsolarpanel to power your boat, RV, truck, or trailer off-the-grid. With a combination of 100 watts of solar panel and 100Ah of Dakota Lithium batteries, this kit offers enough power to charge most single 12-volt battery banks. Additional panels are recommended for colder climates, faster charging, or winter activities. The marine grade solar panel is designed for extreme conditions and is waterproof and flexible, making it suitable for curved roofs and boat decks. It also comes with a 25 year output warranty. The universal installation hardware, including a quick-connect solar plug, stainless steel mounting hardware, and double sided industrial welding tape, makes for easy installation on most surfaces.

Technical Specifications :

100W Solar Panel Charger Specifications

• Max Power (Pmax):

  • Output: 100 Watts
  • Current: 5.56 Amps (peak power generation)
  • Note: Solar panel output is influenced by latitude and season. Consider adding an additional panel for winter camping in northern latitudes.

• Max Power Voltage:

  • 18 Volts (V) – Direct connection to the battery is possible for simple systems.
  • Recommendation: A solar charge controller is highly recommended to lower the voltage to 14.4V, increasing system efficiency.

• Simple Installation:

  • Pre-assembled mounting hardware and wiring for easy setup.
  • Optional: Add a DL Dashboard integration kit for a solar charge controller, battery monitor, and additional wiring harness.

• Mounting Hardware Included:

  • Features: Stainless steel hardware ensures secure mounting, even off-road.
  • Alternative: Double-sided industrial welding tape for curved surfaces, like boat decks or airstream trailers.

• Flexible and Durable Design:

  • Material: Semi-flexible, marine-grade solar panel with a rugged, waterproof backing.
  • Usage: Ideal for rooftops and boat decks. Not designed for foot traffic, which may reduce lifespan and warranty.

• How Long to Charge My Battery?

  • Calculation: Divide the Ah (capacity) of your battery by 5 to determine charging time.

• Cable / Wiring:

  • Length: 3 ft wire harness with waterproof MC4 connectors.

• Size:

  • Dimensions: 47.25 in (1200.15 mm) x 21.25 in (539.75 mm) x 0.1 in (3 mm) per panel.

• Weight:

  • 5 lbs

• Maximum Power Voltage:

  • 18 Volts

• Warranty:

  • 25-Year Power Output Warranty – Ensures the panels generate power for 25 years.

• Waterproof Rating:

  • IP67 Marine Grade – Suitable for use on boats, RVs, and rooftops in the rain.
