BEP Products

BEP Products Resources and Information

PartsVu is happy to offer a complete selection of certified BEP marine products. All electrical components manufactured by BEP are designed for easy integration into any marine vessel’s electrical system, regardless of the system’s complexity. BEP has become one of the most trusted names in the marine industry. Choose from our selection of BEP switches, wires, battery clusters, and more to find out why.

Browse our broad selection of marine products and accessories, or shop BEP products by category, including:

• BEP Battery Switches
• BEP Pro Installer Bus Bar
• BEP Battery Distribution Clusters
• BEP Pro Installer - Link Bus
• Bep Digital Voltage Sensing Relay
• BEP Pro Installer. Insulated Studs
• BEP pro Installer, ANL Fuse Holders

BEP Products FAQs

What is a BEP Pro Installer battery switch?

The Pro Installer range of premium quality battery switches offer ease and flexibility of installation, and optimal performance in the harsh marine environment. With models that offer on/off, selector and dual bank control functionalities, the switches feature improved contactor design, ergonomics that provide clear intuitive operation, an industry standard mounting footprint and all switches meet global industry standards. The innovative dual bank control switch offers the functionality of three switches in one. The patented EZ-Mount switch range allows wiring from the front simplifying installation and saving labor. All Pro Installer EZ-Mount switches feature a common interconnection height with the full line of Pro Installer power management products, which allow them to “cluster” with other products utilizing solid link bars. Attention to all aspects of switch function and use has created superior installation options, high power capacity and improved reliability.

• Meets global industry standards UL1107, CE and ABYC
• Ignition protected
• IP66 rated (see inside back cover)
• Removable side plates
• Ergonomic removable switch knobs

What is a BEP Pro Installer Standard Mount switch?

This powerful generation of battery switches have a 400A rating with outstanding performance and features for both the installer and end user. Three mounting options: surface, rear panel and front panel mounting, plus optimized cable access makes installation a breeze. Pro Installer switches set the new benchmark with outstanding ergonomics, intuitive look/feel, and are engineered from the finest materials to withstand the harsh marine environment.

• Switch studs face back of switch (when viewed from front)
• Panel mounting allows direct access to the switch studs from rear of panel
• Does not share Pro Installer interconnection height due to different mount options
• Accepts metric or imperial fasteners with innovative nut retention

Why should I use a Pro Installer EZ-Mount?

As easy as 1, 2, 3, these revolutionary, patented battery switches from BEP allow you to wire from the front. Simply remove the back, wire, and then clip the actuator and cover in place. Never has installation been so easy. These durable switches accept large cables or multiple lugs and feature intuitive, ergonomic switch positioning and clear graphics. The EZ-Mount switches have a compact, industry standard footprint, the ability to cluster with other Pro Installer products saving valuable onboard space, and are rated 400A continuous, 600A intermittent. Constructed for longevity in the marine environment, they meet rigorous global standards.

What is the BEP Pro Installer series?

Onboard power demands continue to increase as boaters request the comforts of home on their boats. BEP looked at the common products used by electrical installers every day and made significant improvements to their design and construction. The result is a robust product line with greater capacity and extended product life. The valuable space saved onboard gives builders or installers greater flexibility when designing power systems. Since Pro Installer modular assemblies are designed for fast, flexible installation in tight spaces, it's easy to “cluster” products and reduce their mounting footprint. The common interconnection height enables solid link bars to connect multiple Pro Installer products — a smart design feature for watercraft. Like all BEP products, you can be assured of durable construction engineered specifically to handle the challenging marine environment. High-temperature, fiber-reinforced base material provides strength and chemical resistance. All Pro Installer products include a common interconnection height, label recess on the cover, ability to “cluster” and a compact

footprint. All studs, washers and nuts are made of stainless steel.

• Common interconnection height makes it easy to ‘cluster’ products
• Modular assemblies offer unrivaled flexibility in design/layout
• Reduced individual footprints save additional space for the most compact installations
• Robust construction for the harshest of marine environments

What are fuse holders?

These ANL fuse holders offer unparalleled circuit protection choice for both the installer and end-user. The innovative Through-Panel fuse holder (778-ANLTP) provides superior access for fuse inspection and replacement. Small electrical loads are catered to with the compact 778-ANL unit while additional cable security and highest capacity is provided by the 778-ANL-2S, featuring additional studs for separate clamping of cables.

• Cable connection studs: 8 mm (5/16") studs on 778-ANL, 10 mm (3/8") studs on 778-ANL-TP and 778-ANL-2S
• Fuse mounting studs: 8 mm (5/16")
• Double washers allow any ANL fuse brand to be fitted
• Fuse type: ANL or ANN (fast blow)
• Swinging fuse style allows changing fuse without removal of fastening nuts
• Amperage: determined by fuse sizing, 778-ANL: 35-300A, 778-ANL2S: 35-750A, 778-ANLTP, 35-500A
• 50V DC
• Tinned CDA102 copper conductors 778-ANL-2S
• Tinned CDA260 high conductivity brass conductors 778-ANLTP

Class-T fusing provides the ultimate protection for high power circuits, and where extremely fast fuse blow characteristics are required. Modern battery technologies such as Mastervolt Lithium Ion or AGM are capable of very high short circuit currents which may be beyond the interrupt rating of standard circuit breakers and other types of fuse. Two sizes of Pro Installer Class-T Fuse Holder are available which accommodate fuses from 225-400A, and 450-600A respectively.

• Cable connection studs: 10 mm (3/8") studs
• Fuse mounting studs: 10 mm (3/8") 225-400A holder, 12 mm (1/2") 450-600A holder
• Fuse type: Class-T (JLLN / TJN / A3T)
• Maximum amperage: Determined by fuse sizing, either 400A or 600A
• 50V DC
• High temperature, fiber reinforced plastic base provides strength and chemical resistance
• Clear polycarbonate cover
• Tinned CDA102 Copper conductors
• Stainless steel studs, washers and nuts for longevity in the marine environment
• Metric threads

What are Pro Installer insulated studs?

Pro Installer Insulated studs are available in single and twin stud versions, featuring 8 mm (5/16") and 10 mm (3/8") variants. A double stud version with 10 mm and 8 mm studs is also included for extending outboard motor cables. The Power Tapping Plate single stud models provide convenient termination points for additional small cables. Pro Installer family features are replicated with these insulated studs, generous stud length, modular footprint, insulating covers with label recess, and common interconnection height.

• Power tapping plate: 4x 4 mm (5/16") terminals
• Maximum current through power tapping plate: 50A per terminal (4x 50A maximum)
• Note: no power passes through the stud so no amp rating is given 50V DC
• High temperature, fiber reinforced plastic base provides strength and chemical resistance
• Clear polycarbonate cover with snap-out extra cable access
• Stainless steel studs, screws and nuts for longevity in the marine environment
• Insert molded studs with metric threads
• Double studs feature ‘snap out’ insulating partition, to allow linking of studs

What makes Navico Group products unique?

Navico Group is the world’s leading supplier of integrated systems and products to industries

ranging from marine to recreational vehicles. We bring together the best brands, products and

people to create groundbreaking innovations that reinvent the consumer experience. Their broad portfolio of the industry’s leading brands in power management, digital control & monitoring, networked devices, and marine electronics are distributed globally to a diverse aftermarket and OEM customer base. Navico Group is driven, every day, to be the world’s most trusted partner to the marine and mobile industries, and beyond.

BEP offers a range of high quality electrical solutions designed for the harsh Marine and RV environments. Every product meets exacting performance specifications and is designed to withstand extreme conditions, both at sea, and on land.

The BEP team is intimate with the marine environment and develops solutions that improve the installation and use of the products they design. The new products developed reduce assembly time, save space and improve the user experience.

BEP's innovative culture and engineering excellence is focused on simplifying the installation and optimizing the user experience with thoroughly tested products that will thrive in the harsh marine environment.

BEP customers have global support in APAC, EMEA and the Americas. The network of support will resolve any issues that come up in supply, technical support and installation questions. BEP is committed to provide the products and support needed to make your installation and experience the best in the industry.

BEP engineers and manufactures a range of high quality electrical solutions designed for the harsh Marine and RV environments. Shop PartsVu.com's complete selection of BEP electrical products to find the one that matches the exact specifications of your marine vessel's electrical system.
