Mercury – Trim Tab Interface Kit | Digital K-Plane to SmartCraft Link | 8M0100069

Overview

Digital K-Planes deliver precise trim control, but they need the right bridge to show their position on SmartCraft instrumentation. The Mercury 8M0100069 Trim Tab Interface Kit creates that link, sending accurate K-Plane trim data directly to SmartCraft gauges and displays. It turns the tabs’ digital readings into clear, reliable information at the helm, making it easier to see and adjust tab position while running.

Key Features

• SmartCraft Display Link – Feeds digital K-Plane trim position directly to SmartCraft gauges.
• Digital K-Plane Compatible – Designed specifically for use with Mercury’s digital K-Plane systems.
• Accurate Trim Feedback – Provides clean, real-time tab position data to the helm.
• Plug-In Integration – Uses OEM connectors for a clean, direct SmartCraft interface.
• Improved Helm Awareness – Gives the driver a clearer picture of boat attitude through SmartCraft instrumentation.
• Durable Marine Build – Engineered to handle vibration, heat, and long-term offshore use.

Compatibility

• Digital K-Plane trim systems
• SmartCraft gauges and helm displays
• SmartCraft CAN networks requiring tab-position input

Performance & Practical Benefits

This interface makes it easier to monitor K-Plane trim at a glance. With the tab position displayed on SmartCraft instrumentation, the helm becomes more intuitive, especially when balancing the boat at speed or dialing in attitude in rough water. The connection is direct and stable, giving you clean feedback without lag. It keeps the dashboard organized and improves confidence when adjusting trim under load.

Why Buy OEM

Digital K-Planes require precise communication with SmartCraft for accurate trim reporting. Mercury’s OEM interface kit uses the correct logic and connectors, ensuring the data shown on the gauge is true to the tab’s actual position. Aftermarket solutions often miss timing or scaling details, which leads to inaccurate readings. The OEM kit installs easily and delivers the reliability needed for high-performance running.

FAQ

Q1: When is this interface kit required?
Whenever digital K-Planes need to send their trim position to SmartCraft gauges or displays.

Q2: Does it change how the tabs operate?
No. It only transmits position data—the tab operation remains unchanged.

Q3: Is this kit compatible with analog K-Planes?
No. It is designed only for digital K-Plane systems.

Q4: How hard is the installation?
Straightforward—plug into the SmartCraft network and the digital K-Plane harness using OEM connectors.

Q5: Will the reading be real-time?
Yes. SmartCraft displays show live position data once the interface is connected.
