Mercury – Resistor Pack DTS Shadow Mode (#97) | Shadow Load Module | 898091T03

Overview
This resistor pack is used on triple-engine DTS Shadow Mode setups that run two helms. It provides the correct load for the network so Shadow Mode doesn’t act jumpy or fall out of sync between stations. This #97 pack is the one used at Helm 2 and Starboard 2, and it’s already included with the lower or primary helm kits in the 895816A–895819A series. It’s a small part, but it keeps a dual-helm Shadow Mode setup behaving smoothly.

Key Features
• Shadow Mode Resistor Pack #97 – Supplies the correct load for dual-helm Shadow Mode.
• Helm 2 + Starboard 2 Positioning – Built for the specific resistor locations in triple-engine layouts.
• Triple-Engine Ready – Designed for three-engine DTS Shadow Mode rigs.
• Dual-Helm Use – Intended for systems with upper and lower control stations.
• OEM Spec – Fits 2006-and-newer Gen I DTS setups.

Engine & Boat Compatibility
• Digital Throttle and Shift Gen I
• Triple engine
• Dual-helm installations
• Shadow Mode systems (2006+)

Performance & Practical Benefits
With the right resistor in place, Shadow Mode responds smoothly across all three engines, even when switching between helms. The system doesn’t “hunt” or lag because the network load stays where it’s supposed to be. Docking and slow-speed work feel more controlled, and troubleshooting is easier since the electrical path stays stable. It’s a simple part that helps the whole system feel more predictable.

Why Buy OEM
OEM resistor packs match Mercury’s DTS specs exactly, so you don’t run into odd glitches or timing issues between engines. They’re built to handle real marine conditions—vibration, heat, and moisture—far better than generic electronics. It’s the reliable choice for a system that needs precise communication.

FAQ
Q1: How do I know this is the resistor pack I need?
A: If you’re running a triple-engine, dual-helm DTS Shadow Mode setup (2006 or newer), #97 is the correct pack for Helm 2 and Starboard 2.

Q2: Is it already included in some helm kits?
A: Yes—it's included with 895816A, 895817A, 895818A, and 895819A series helms.

Q3: Does it require calibration?
A: No—install it and the DTS system handles the checks automatically.

Q4: How does it hold up in saltwater?
A: Very well. Just rinse and check connections occasionally.

Q5: What are early signs of resistor issues?
A: Uneven Shadow Mode timing, hesitation when switching helms, or intermittent communication.
